PoE-Kytkin 24-porttia, 24 IP-kameraa

SF124  PoE-Kytkin 24-porttia, 24 IP-kameraa                     tilaustuote

• Application: The SF124 is a 24-port PoE designed to supply IP cameras operating in the IEEE 802.3af/at standard. Automatic detection of any devices powered in the PoE/PoE+ standard is enabled at the 1 – 24 ports of the switch.
• Power supply: 90÷264VAC
• The number of ports: 26 ports (24xPoE + 2xUPLINK)
• PoE supply: 24 ports 10/100 Mb/s - IEEE 802.3af/at, 52VDC / 30W/port (PoE+)
• UPLINK port: 2 ports 10/100/1000 Mb/s – G1/TP, G2/TP – for recorder / switch / computer installation
• Outlets: SFP UPLINK: 2 ports 10/100/1000 Mb/s – G1/SFP, G2/SFP - for recorder / switch / computer installation
• Dimensions: W=442 H=44 D=224 [+/- 2mm]
• Notes:G1/TP and G1/SFP connectors can not operate simultaneously
• G2/TP and G2/SFP connectors can not operate simultaneously
• Supported protocols and standards: IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP
• 30W/port - the maximum power of a single PoE port
• 240W – the maximum total power for all PoE ports
• PoE supply - pairs: 4/5 (+), 7/8 (-)
• Port sockets: RJ45, SFP
• mounting brackets for RACK 19” included
