Huippu Testimonitori - kamera ja verkkotyökalu

HYU-1076 All-in-One  Huippu Testimonitori - kamera ja verkkotyökalu

• HYUNDAI All-in-one tester for 8K security camera testing
• 7" retina touch screen (1280x800)
• Supports 8MP TVI/CVI/AHD/AHD/SDI and 8K H.265 IP cameras test
• Test Onvif Dahua, Hikvision, Axis, etc. cameras
• HDMI 4K input (30 fps)
• HDMI 4K output (60 fps)
• VGA 1080P input
• Power output 24V/2A, 12V/3A and 48V PoE (up to 30 W)
• Dual Gigabit Ethernet ports
• UTP cable test / RJ45 cable TDR test, quality test
• TesterPlay, supports remote control and voice intercom
• Backlit buttons for use in the dark.
• All-in-one tester for 8K security camera testing
• Used for installation and maintenance of IP cameras, analog cameras and other security equipment
• Numerous App tools and automatic OS update support
• 7" retina touch screen (1200x800 pixels)
• 8K H.265 video display through main stream
• 8MP (3840x2160) TVI test at 15 fps, 4X zoom, video recording and playback, coaxial PTZ control and OSD menu calling
• 8MP (3840x2160) AHD test at 15 fps, 4X zoom, video recording and playback, PTZ coaxial control and OSD menu call
• 8MP (3840x2160) CVI test at 12.5/15 fps, 4X zoom, video record and playback, coaxial PTZ and OSD menu call
• 8MP EX-SDI test (3840x2160) at 25/30 fps, 4X zoom, video record and playback, coaxial PTZ and OSD menu call
• 2MP HD-SDI test (1920x1080) at 25/30/50/60 fps, 4X zoom, video recording and playback, coaxial PTZ and OSD menu call
• 2MP 3G-SDI test (1920x1080) 50/60 fps, 4X zoom, video recording and playback, coaxial PTZ and OSD menu call
• Fast ONVIF, auto login and image display, test report creation
• CVBS camera test and PTZ control
• IP camera test (non-ONVIF), HIK test tool for Hikvision cameras and DH test tool for Dahua cameras
• Video level meter, peak video signal level, SYNC signal level, color bar chroma level measurement
• 24V DC /2A, 12V DC /3A power outputs (camera can be powered from tester)
• 48V PoE with a maximum output power of 30W
• Fast, one-touch video to detect all network cameras and automatic display
• Built-in WiFi to display wireless camera image and create WIFI hotspots
• CVBS loop test to send and receive color bar generator signal to test BNC cable
• Enhanced color bar generator, PAL/NTSC multi-system color bar video generator
• Cable upgrading test, UTP cable test, telephone cable test etc.
• RJ45 cable TDR test which allows you to check the cable pair condition, length, attenuation, reflectivity, impedance, bias etc.
• Enhanced Digital Cable Tracing, searching BNC cable, network cable and telephone cable for cable clutter, with higher accuracy.
• TDR test: BNC cable, network cable, telephone cable, RVV cable, elevator cable and cat 5/6 cable length and short-circuit
• Professional WIFI analyzer, detect surrounding wifi signal and signal strength
• Network tool: Ping, IP scan, Port Flash, DHCP server, Trace Route
• TesterPlay: Tester, android version cell phone and PC display simultaneously
• Shortcut button, drop-down menu, you can select Poe power, IP setting, CVBS, LAN information, HDMI IN etc.
• Traffic monitoring, display network port or WIFI connection in real time upload and download speeds and other network parameters
• Auto-update software, can install applications with android version.
• Media player, playback of 4K video files and MKV/MP4 media files
• 8GB SD card included
• Audio input
• LED lamp, calculator, music player and other tools
• 7.6V /7800mAh battery, fast charging in 3.5 hours, working time 16 hours
• Working temperature: -10°C ~ +50°C
• Dimensions: 240 x 154 x 46 mm
• Included apps: EVOPLUS, HYUVMS, ASMS, HYU CONNECT, HYUPLUS
