ZVR Tallennin, 4 kanavaa+4 IP kameraa, aisense

ZVR-996  5in1 Tallennin, 4 BNC kanavaa+4IP

• ZVR 5 in 1 HYUNDAI 4 channel
• 4 channels BNC 8MP + 4 channels IP 8MP
• 5 technologies: IP, HDCVI, HDTVI, AHD and analog CVBS cameras
• H.265+/H.265 formats
• 8MP@15ips recording
• Independent HDMI 4K and VGA 1080P outputs
• Bidirectional audio, audio over coaxial
• Motion detection 2.0
• Supports 1 HDD 10TB, 1 RJ45 Gigabit, 1 RS485, 2 USB, Onvif.
• Connectable to H.265+/H.265/H.264+/H.264+/H.264 IP cameras
• H.265+ compression format improves encoding efficiency by up to 80% and reduces video data storage costs
• 4 BNC inputs (supports coaxitron):
  • HDCVI: 4MP, 1080P, 720P
  • HDTVI: 8MP, 3K, 5MP, 4MP, 3MP, 1080P, 720P
  • AHD: 5MP, 4MP, 1080P, 720P
  • Analog CVBS: 960H, PAL/NTSC
• 4 IP inputs up to 8MP (4+4)
• Independent HDMI (4K) and VGA (1080P) outputs
• BNC video output
• Audio channels: 1 RCA input / 1 RCA output
• Bi-directional audio: via RCA audio channel 1
• Supports coaxial audio (4 outputs)
• Recording resolution: 8MP, 5MP, 3K, 4MP, 3MP, 1080P, 720P, WD1, 4CIF, VGA, CIF
• Stream 1: 8MP (12/15 fps), 3K (20 fps), 5MP (12/20 fps), 3MP (18 fps), 4MP, 1080P, 720P, WD1, 4CIF, VGA, CIF (25/30 fps)
• Stream 2: WD1, 4CIF, CIF (25/30 fps)
• 4-channel synchronized playback
• Long distance HDTVI transmission: up to 1200 meters at 720P and 800 meters at 1080P
• Internal capacity for 1 SATA HDD up to 10TB (sold separately)
• Intelligent search
• Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
• Supports cross-line detection and intrusion detection on all channels, as well as sudden scene change detection on 2 channels
• Motion detection 2.0: Deep learning-based motion detection 2.0 is enabled by default for all analogue channels, can classify people and
• vehicles and minimise false alarms caused by lights or objects such as leaves
• Auto-adaptive RJ45 Ethernet (10/100/1000M) network interface
• Network protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS
• Remote access for up to 32 users
• Onvif support
• P2P in the cloud, DDNS DEMES, Push and zero channel
• Connections: 1 USB 2.0, 1 USB 3.0, 1 RS485
• Power supply: 12V DC, 2A
• Power consumption: ≤10W
• Operating temperature: -10°C ~ +55°C
• Relative humidity: 10~90%.
• Dimensions: 315 (W) x 45 (H) x 242 mm (desktop)
• Weight: ≤1.8 kg
